BraunAbility B&D Transfer Seat

Top of the line swivel seating solution engineered for easy transfers to the driver or passenger seat in your wheelchair accessible vehicle.

BraunAbility B&D Transfer Seat Features:

BraunAbility B&D Transfer Seat Features:

Original Vehicle Seat

The BraunAbility transfer seat utilizes the original vehicle driver or front passenger seat to maintain all the safety and comfort features that come standard in your vehicle. This allows transfers in your wheelchair accessible vehicle easier.

Easy Operation

Using your choice of a pendant, control box, or both, the transfer seat base swivels toward the center of your accessible vehicle to allow for comfortable and safe transfers into the driver or front passenger seat.

No Permanent Modifications

The transfer seat base mounts to the original mounting holes and “L” track system and does not require extra drilling on most applications. You can remove the transfer base and reinstall the quick release seat base if needed.

180-degree Turn Option

Choose a 100-degree or 180-degree swivel based on your personal comfort and transfer needs. Your mobility dealer technician will be able to adjust the transfer seat to your needs.

Safety Features Built-In

The built-in passive interlock ensures the transfer seat base is returned to the standard driving position every time after operation to preserve the functionality of the air bag and seat belt functions. Once the vehicle is in operation, this feature prevents the transfer seat base from accidentally activating. If adjustments are needed, you can override this feature for comfort and convenience.


Transfer Seat Options

Optional Accesory

Pendant Control Operation

Optional Accesory

Switch Box Operation

Optional Accesory

Extended Harness for BraunAbility

Optional Accesory

Transfer Height Variety

Compatible Vehicles

Transfer seats can be installed in lowered floor wheelchair accessible vehicles and some full size vans.

Vehicle Type
Side-Entry Foldout XT Power Ramp
Vehicle Type
Side-Entry Infloor Power Ramp
Vehicle Type
Side-Entry Foldout Power Ramp
Vehicle Type
Full Size Van Options

Additional Transfer Seat Information

Capability

BraunAbility B&D Transfer Seat Warranty

The BraunAbility B&D transfer seat has a 36-year limited parts and 12-month labor warranty. To protect your warranty, any repair or replacement work must be completed by a BraunAbility certified technician.

Capability

Standard Transfer Seat Specifications

  • Travel Horizontal: 17.5”
  • Travel Vertical: 6.25”
  • Swivel: 100 s
  • Weight Capacity: 500 lbs (Occupant)
  • Length: 36.25″
  • Width: 13″
  • Down Height: 7.25
Capability

Extended Transfer Seat Specifications

  • Travel Horizontal: 18"
  • Travel Vertical: 21"
  • Extended Swivel: up to 180° (with extended harness)
  • Weight Capacity: 500 lbs (Occupant)
  • Length: 36.25″
  • Width: 13″
  • Down Height: 7.25"
  • Down Height without Brackets 6.75”
Capability

Transfer Seat Features

  • Driver or front passenger position
  • Utilizes original vehicle seat while maintaining seat functions
  • Transfer Seat Base mounts to the original mounting holes and “L” track system. Does not require extra drilling on most applications
  • Second-row seating area remains open
  • Can be driven in any up/down position
  • Can be driven up to 4” back from the full forward position
  • Adjustable rotation speed
  • Design conceals scissor legs for owner safety and appearance
  • Choice of side-mounted switchbox, coiled cord handheld pendant, or both
  • Extended seat harness
Capability

Optional Features

  • Additional controller (switchbox or handheld pendant)
  • 180-degree swivel
  • Custom colors (black, light gray, charcoal, or tan)

Downloads and Resources

Manuals:

Manual

BraunAbility B&D Transfer Seat Manual

DOWNLOAD

Brochures:

Brochure

BraunAbility B&D Transfer Seat Brochure

DOWNLOAD

Videos:


Form Container - mobility-product-guide24,mobility-product-guide
Please add openform-mobility-product-guide24,mobility-product-guide class to buttons to show this form.
Please submit the following contact form.
Looking for more information about our mobility products? Fill out the form below to download our Mobility Product Guide.

Please submit the following contact form.

*
Please enter your first name.
*
Please enter your last name.
*
Please enter a valid email address. (example@domain.com)
*
Please enter a valid zip code.
Please enter a valid phone number.
*
*
Please choose a contact method.

4 msg/month, message & data rates may apply. Reply STOP to CANCEL; HELP for HELP

By selecting this box, you confirm that you would like to receive email promotions, surveys and offers from BraunAbility. Note that your email interactions can be used to produce content & ads tailored to your interests. Please consult our Privacy Policy and Cookie Policy for complete details, including how to manage your privacy and communication settings.

View our Mobile Terms & Conditions | View our Privacy Policy | View our Cookie Policy

Please check the invalid fields.
There was an error submitting the form. Please try again later.
Thank you for submitting the form.

Not sure which BraunAbility product is right for you?

Check out our 2024 Mobility Product Guide to see our full lineup of accessible vehicles and seating.




Purchasing Your BraunAbility B&D Transfer Seat

The BraunAbility transfer seat provides seamless mobility for those desiring to transition from their wheelchair to the original driver or passenger seat. Offering 180-degree turning power, this transfer seat ensures a comfortable experience transferring from your wheelchair in your wheelchair-accessible vehicle.

Finance is also available through BraunAbility Finance and your local mobility dealer. Your purchase could also be eligible for automotive manufacturer rebates.

Find Your Dealer
Purchasing

Financing Your BraunAbility B&D Transfer Seat

Financing is available for the BraunAbility Transfer Seat and could not be easier. BraunAbility Finance has easy solutions with a 60 second pre-qualifications process with no impact on your credit. You can view instant, customized finance offers and work with your local mobility dealer for convenient installation times to get you back on the roads with ease and comfort.1

Apply for Financing
Form Container - generic-contact,generic-contact
Please add openform-generic-contact,generic-contact class to buttons to show this form.
Call us at 1-800-488-0359 or complete the form below.
Looking for more info?

Call us at 1-800-488-0359 or complete the form below.

*
Please enter your first name.
*
Please enter your last name.
*
Please enter a valid email address. (example@domain.com)
Please enter a valid phone number.
*
Please enter a valid zip code.
*
Please select your country.

4 msg/month, message & data rates may apply. Reply STOP to CANCEL; HELP for HELP

By selecting this box, you confirm that you would like to receive email promotions, surveys and offers from BraunAbility. Note that your email interactions can be used to produce content & ads tailored to your interests. Please consult our Privacy Policy and Cookie Policy for complete details, including how to manage your privacy and communication settings.

View our Mobile Terms & Conditions | View our Privacy Policy | View our Cookie Policy

Please check the invalid fields.
There was an error submitting the form. Please try again later.
Thank you for submitting the form.


Frequently Asked Questions

Does the BraunAbility B&D Transfer Seat work for a person in a wheelchair?

+

Absolutely. Our transfer swivel seat is designed specifically for individuals in wheelchairs, providing 180-degree turning power to facilitate easy transfers into the original driver or front passenger seat.

How do you transfer from a wheelchair into a handicap accessible passenger seat?

+

Utilizing a pendant or control box, the transfer seat base smoothly turns toward the center of your lowered-floor accessible vehicle, enabling comfortable and secure transfers from a wheelchair into the driver or front passenger seat.

Is the BraunAbility transfer seat compatible with most wheelchair accessible vehicles?

+

Absolutely. The transfer seat is safety-tested and compatible with a wide range of wheelchair accessible vehicles including BraunAbility side-entry options, making it a versatile and reliable solution.

Does the installation of the transfer seat require additional drilling into the vehicle floor?

+

No, in most cases, the transfer seat installation does not require extra drilling. It is designed to mount securely to the original vehicle driver or front passenger seat using the existing mounting holes and "L" track system.

Can the BraunAbility transfer seat be operated from any seat position?

+

Our transfer seat base is designed for optimal comfort and convenience and allows consumers to transfer to the front driver or passenger position. This allows you to have the flexibility and ease of use that you expect from BraunAbility.
